product description

Classification Function Description

Audio coding sampling rate 16k, 32k, 44.1k, 48k

Code rate range can be set arbitrarily, recommended 64k~256kbps

Encoding format AAC, PCMA, MP3, MP2

Gain adjustment -24db ~ +24db

The default is 0: do not adjust the gain

Video encoding bit rate range reference model comparison table

Rate control CBR, VBR, AVBR, FIXQP

Encoding format H.264, H.265

The resolution supports 3840 * 2160/2560 * 1440/2048 * 1152 / 1920x1080p / 1920x1080i / 1280x720p

/ 720 * 576i / 720 * 576p / 640 * 480i and other resolutions (can be customized)

Encoding protocol H.265 Main Profile, Level 5.0

H.264 Baseline/Main/High Profile, Level 5.1

Smart coding SmartP, DualP, ROI

Video processing Rotation support 90, 180, 270 degree rotation

Crop support up, down, left and right cropping

De-interlacing support normal de-interlacing, full frame rate de-interlacing

Network protocol General protocol HTTP, HLS, RTSP, RTMP streaming, RTMP streaming, UDP, multicast

SRT support

NDI support

Other functions Video mixing Support 9-square grid, 4 pictures, 1+2, picture-in-picture, custom and other layouts to switch arbitrarily

Special effects overlay Logo, watermark, subtitles, rolling subtitles, mosaic, time stamp

Multi-platform live streaming supports simultaneous live streaming on any multiple platforms

File Carousel Stream the files in the FAT32 format U disk into a live stream

File recording: Support recording each channel to FAT32 format U disk

Network input Support rtsp, rtmp and other formats of network stream input decoding, re-encoding, director, etc.

Group management All encoders in the local area network can be configured synchronously, and the program list can be summarized
