Product Overview

TUOYING TN1201D is a professional high integration device which includes tuner demodulation, multiplexing. It supports 2-12 tuner input(support different types of tuner ( DVB-S2/DVB-C/DVB-T/ATSC/DTMBT/ISDBT, etc. ) input),Support PCMCIA card descrambling, 1000M IP output, MPTS and SPTS output。In conclusion, its high integrated and cost-effective design makes the device widely used in varieties of digital distribution systems such as cable TV digital head-end, digital TV broadcasting etc.

Key Features

Support 2-12 channels PCMCIA card descrambling, single module provides 2 channels (2 Tuner+2 PCMCIA slots), a maximum of 6 modules support a total of 12 PCMCIA card channels.

the tuner supports (DVB-S2/DVB-C/DVB-T/ATSC/ISDBT/DTMBT)

 1000M IP output over UDP and RTP protocol ,8 MPTS and 512 SPTS(The multiplexed version has 4 MPTS/512 SPTS output)

 2 ASI inputs and 2 ASI Independent output

 Support “Null PKT Filter” function

 Support PID Remapping/ PCR accurate adjusting

 PID pass

 LCD、key function

 Control via web management, and easy updates via web

Technical Specification

input 2/4/6/8/10/12 tuner;

and the tuner supports (DVB-S2/DVB-C/DVB-T/ATSC/ISDBT/DMBT)

2 ASI inputs

output 2 ASI output

IP output（512 SPTS and 8 MPTS）IP output over UDP and RTP protocol (The multiplexed version has 4 MPTS/512 SPTS output)

Multiplexing Maximum PID Remapping 180 output PID per channel

Function PID remapping (automatically or manually)

Accurate PCR adjusting

System function Network management (WEB)

Chinese and English language

Ethernet software upgrade

Miscellaneous Dimension(W×L×H) 482mm×410mm×44mm

weight 5-9 kg

Environment 0~45℃(work)；-20~80℃(storage)

Power requirements AC100~240V，50/60Hz

Power dissipation <90W

Note: A single module provides 2-channel PCMCIA card descrambling, and supports a maximum of 6 modules with a total of 12 PCMCIA card channels, the number of channels is optional as a multiple of 2.
