Product Parameter

Specification Parameter

Audio and video in Video in 1 HDMI

Audio in 1 HDMI Built in audio 1 External audio

Video encode Encoding type H.264/H.265

FPS 5-30

GOP 5-300

Bit rate(k bit) 32-32000

Maximum support 1920x1080P60

Encoded size 1920x1080/1680x1056/1280x720/1024x576/850x480/720x576/720x540/720x480/720x404/704x576/640x480/640x360/608x448/544x480/480x480/480x384/480x360/480x320/480x272/480x270/400x320/400x224/352x480/352x228/320x256/320x240/320x180/240x180/same as the input

H.264 level baseline profile/main profile/high profile

Bit rate control CBR/VBR

Stream RTMP/ RTSP /HTTP TS/HTTP FLV/HLS/UDP/RTP

Audio encode Audio input HDMI/ANALOG

Sample rate 44100/48000

Encoder AAC/AAC+/AAC++/MP3/MP2/AC3

Coding bit rate AAC:48000-256000/AAC+:24000-48000/

AAC++:12000-32000/MP3:64000-320000/

MP2: 64000-320000/ AC3:40000-640000

Digital volume -50~50

G711A Over RTSP Disable/Enable/Enable and resample with 8k

OSD Transparency 0-128

Type Text/Img/Scrolling text

Zone 4 Zone

X 0-1920

Y 0-1080

LOGO 4 logos can be uploaded for selection

Font size 8-72

Background color Transparent/White/Black

Font color RGB color

Common Network 100Mbps

Configuration WEB,Upload,Reset

ONVIF Support ONVIF to search and browse videos

Power Supply 12V/DC,2A

Power <2W

Temperature -20℃+60℃

Humidity <90%, non-condened

Size 8.4cm x 5.3cmx2.7cm
