Product Description
The TYE-1002 4/8-channel HD encoder is a robust and versatile solution for IPTV, CATV, and live streaming applications. It supports a wide range of video resolutions, from 1920x1080 to 480x272, ensuring that your content is delivered with the highest possible quality. The encoder's H.264/H.265 HEVC encoding capabilities provide efficient compression, allowing for smooth streaming even over low-bandwidth networks. With an adjustable bit rate from 32 to 32000 kbit, you can tailor the video quality to suit your specific needs and network conditions.
Product Features
1 The encoder's audio capabilities are equally impressive, supporting a variety of audio formats including AAC, AAC+, AAC++, MP3, MP2, and AC3. This flexibility ensures that your audio content is encoded with the highest level of fidelity, whether you're broadcasting music, podcasts, or voiceovers. The adjustable sampling rate from 44100/48000 Hz and bit rate from 64000 to 3200000 kbit allow for precise control over audio quality, ensuring that your audio is as crisp and clear as the video.
2 With support for RTMP, RTSP, HTTP TS, HTTP FLV, HLS, UDP multicast, and RTP multicast, this encoder is compatible with a wide range of streaming protocols and platforms. This makes it an ideal choice for both small-scale live streaming setups and large-scale IPTV and CATV deployments. The encoder's OSD transparency and type options, including text, picture, and scrolling text, provide a customizable user experience, while the 16 LOGO upload options allow for branding and personalization of your streaming service.
3 The encoder's robust design ensures reliable performance in various environmental conditions, with a working temperature range of -20℃ to 60℃ and humidity levels below 90% non-condensing. Its compact size of 2.7cm x 17.5cm x 11.1cm and lightweight design of 2KG make it easy to integrate into any setup. The user-friendly web-based configuration management system allows for easy setup and management of the encoder, ensuring that even non-technical users can operate it with ease. Whether you're a small business or a large-scale broadcaster, this encoder is designed to meet your streaming needs with efficiency and reliability
Specification parameters
Audio and video input Video input 4/8 HDMI-compatible
Ranch
Video encoding encoding type H.264 / H.265
H.264 level Baseline / Main / High optional
Encoding frame rate 5-60 adjustable
Key frame interval (frame) 5-300 adjustable
Bit rate (kbit) 32-32000 adjustable
Encoding resolution 1920x1080 / 1680x1056 / 1280x720 / 1024x576 / 850x480 / 720x576 / 720x540 / 720x480 / 720x404 / 704x576 / 640x480 / 640x360 / 608x448 / 544x480 / 480x480 / 480x384 / 480x360 / 480x320 / 480x272 / 480x270 / 400x320 / 400x224 / 352x480 / 352x228 / 320x256 / 320x240 / 320x180 / 240x180 / same as input resolution
Stream control CBR / VBR optional
Stream support RTMP / RTSP / HTTP TS / HTTP FLV / HLS / UDP multicast / RTP multicast
Audio encoding Audio input Digital / analog / mixed
Encoding sampling rate 44100/48000 optional
Coding method AAC / AAC + / AAC ++ / MP3 / MP2 / AC3 optional
Encoding bit rate AAC: 48000-256000 adjustable / AAC +: 24000-48000 adjustable /
AAC ++: 12000-32000 adjustable / MP3: 64000-320000 adjustable /
MP2: 64000-320000 adjustable / AC3: 40,000-640000 adjustable
Digital volume -50 ~ 50 adjustable
RTSP stream uses G711A encoding Disable / Enable Optional
OSD transparency 0-128 adjustable
Type Text / Picture / Scrolling Text
Zone 4 zones to choose from
X coordinate 0-1920
Y coordinate 0-1080
LOGO can upload 16 LOGO options
Font size 8-72
Background color transparent / white / black
Font color RGB color optional
Universal Network Gigabit
Configuration management Configuration management via WEB
ONVIF supports ONVIF to find and browse videos
Power 12V / DC, 2A
<5W
Working temperature -20 ℃ + 60 ℃
Operating humidity <90%, non-condensing
Size 2.7cm x 17.5cm x 11.1cm
Weight 2KG
